Drying wheel dehumidifier

Applicable environment：Widely used in valuables warehouses, pharmaceuticals, food, electronics, leather, footwear, furniture, printing products, chemicals, tobacco and many other industries

Product Features：

Special custom：no

Quality Certification：

Model：AY-D1280EAY-D1550EAY-D1800EAY-D2000EAY-D2500EAY-D3000EAY-D4000EAY-D5000E

Buy Online Download

Product parameter

  1. Product model

  2. Dehumidification capacity (20°C60%)

  3. Handling air volume

  4. Regenerative air volume

  5. Deal with the air inlet and outlet

  6. Regeneration inlet and outlet

  7. heating method

  8. Heating drive

  9. Maximum power

  10. Operating power

  11. Operating current

  12. Handling inlet air filtration

  13. Regenerative air inlet transition

  14. way to control

  15. Applicable voltage/frequency

  16. Whole machine quality KG

  17. Length * width * height mm

  1. AY-D1280E

  2. 8.5kg/h

  3. 1300m³/h(200p a)

  4. 450m³/h(150p a)

  5. φ200mm

  6. φ150mm

  7. Electric-PTC

  8. SCR SCR

  9. 13kw

  10. 11.8kw

  11. 18.5A

  12. Aluminum alloy initial effect

  13. Aluminum alloy initial effect

  14. Meter + button

  15. 380v/50Hz

  16. 125KG

  17. 1178*713*752

  1. AY-D1550E

  2. 10kg/H

  3. 1550m³/h

  4. 580m³/h

  5. φ200mm

  6. φ150mm

  7. Electric-PTC

  8. SCR SCR

  9. 15kw

  10. 13kw

  11. 20A

  12. Aluminum alloy initial effect

  13. Aluminum alloy initial effect

  14. Meter + button

  15. 380-415V/50-60HZ

  16. 110KG

  17. 1178*713*752mm

  1. AY-D1800E

  2. 11kg/h

  3. 1550m³/h(200p a)

  4. 650m³/h(300p a)

  5. φ250mm

  6. φ160mm

  7. Electric-PTC

  8. SCR SCR

  9. 17kw

  10. 15kw

  11. 22.5A

  12. Aluminum alloy initial effect

  13. Aluminum alloy initial effect

  14. Meter + button

  15. 380v/50Hz

  16. 186KG

  17. 1328*755*840

  1. AY-D2000E

  2. 13.5kg/h

  3. 2000m³/h(300p a)

  4. 680m³/h(200p a)

  5. φ250mm

  6. φ200mm

  7. Electric-heating tube

  8. SCR SCR

  9. 22kw

  10. 20kw

  11. 30A

  12. Aluminum alloy initial effect

  13. Aluminum alloy initial effect

  14. Meter + button

  15. 380v/50Hz

  16. 220KG

  17. 1328*755*840

  1. AY-D2500E

  2. 15kg/h

  3. 2500m³/h(300p a)

  4. 900m³/h(200p a)

  5. φ300mm

  6. φ200mm

  7. Electric-heating tube

  8. SCR SCR

  9. 24kw

  10. 22kw

  11. 33A

  12. Aluminum alloy initial effect

  13. Aluminum alloy initial effect

  14. Meter + button

  15. 380v/50Hz

  16. 280KG

  17. 1250*900*1300

  1. AY-D3000E

  2. 19kg/h

  3. 3000m³/h(400p a)

  4. 1100m³/h(250p a)

  5. φ300mm

  6. φ200mm

  7. Electric-heating tube

  8. SCR SCR

  9. 30kw

  10. 28kw

  11. 42A

  12. Aluminum alloy initial effect

  13. Aluminum alloy initial effect

  14. Meter + button

  15. 380v/50Hz

  16. 300KG

  17. 1250*900*1300

  1. Product model

  2. Dehumidification capacity (20°C60%)

  3. Handling air volume

  4. Regenerative air volume

  5. Deal with the air inlet and outlet

  6. Regeneration inlet and outlet

  7. heating method

  8. Heating drive

  9. Maximum power

  10. Operating power

  11. Operating current

  12. Handling inlet air filtration

  13. Regenerative air inlet transition

  14. way to control

  15. Applicable voltage/frequency

  16. Whole machine quality KG

  17. Length * width * height mm

  1. AY-D4000E

  2. 26kg/h

  3. 4000m³/h(400p a)

  4. 1500m³/h(250p a)

  5. φ500mm

  6. φ250mm

  7. Electric-heating tube

  8. SCR SCR

  9. 40kw

  10. 38kw

  11. 57A

  12. Aluminum alloy initial effect

  13. Aluminum alloy initial effect

  14. Meter + button

  15. 380v/50Hz

  16. 450KG

  17. 1800*1300*1700

  1. AY-D5000E

  2. 35kg/h

  3. 5000m³/h(400p a)

  4. 1850m³/h(250p a)

  5. φ500mm

  6. φ250mm

  7. Electric-heating tube

  8. SCR SCR

  9. 52kw

  10. 50kw

  11. 75A

  12. Aluminum alloy initial effect

  13. Aluminum alloy initial effect

  14. Meter + button

  15. 380v/50Hz

  16. 520KG

  17. 1800*1300*1700
