Product model
Range of regulation
Control accuracy
Dehumidification (30℃ 80%)
voltage
power
Maximum power
Air volume
refrigerant
Type of protection against electric shock
Body size
weight
Applicable temperature
Applicable area (height 3 meters)
AY-7.0SD
10% - 95%.
Plus or minus 3%
7kg/h
380V to 50Hz
2700W
3300W
1500m³/h
R22/R410A
Class I
615×405×1565mm
95kg
5 ℃ - 38 ℃
200-250m²
AY-7.5SD
10% - 95%.
Plus or minus 3%
7.5 kg/h
380V-50Hz
3150W
3800W
1800m³/h
R22/R410A
Class I
615×405×1565mm
105kg
5 ℃ - 38 ℃
250-300m²
AY-8.8SD
10% - 95%.
Plus or minus 3%
8.8 kg/h
380V-50Hz
3200W
3900W
2000m³/h
R22/R410A
Class I
760×470×1710mm
126kg
5 ℃ - 38 ℃
300-350m²
AY-10SD
10% - 95%.
Plus or minus 3%
10kg/h
380V-50Hz
3400W
4150W
2300m³/h
R22/R410A
Class I
760×470×1710mm
130kg
5 ℃ - 38 ℃
350-400m²
AY-12SD
10% - 95%.
Plus or minus 3%
12kg/h
380V-50Hz
4700W
5650W
2500m³/h
R22/R410A
Class I
760×470×1710mm
138kg
5 ℃ - 38 ℃
450-500m²
AY-15SD
10% - 95%.
Plus or minus 3%
15kg/h
380V-50Hz
5500W
6600W
3500m³/h
R22/R410A
Class I
980×470×1770mm
176kg
5 ℃ - 38 ℃
500-650m²
AY-20SD
10% - 95%.
Plus or minus 3%
20kg/h
380V-50Hz
6800W
8500W
4000m³/h
R22/R410A
Class I
1200×475×1770mm
230kg
5 ℃ - 38 ℃
650-800m²
AY-30SD
10% - 95%.
Plus or minus 5%
30kg/h
380V-50Hz
11000W
13500W
6000m³/h
R22/R410A
Class I
1200×475×1770mm
280kg
5 ℃ - 38 ℃
800-1000m²
