Product model
Range of regulation
Control accuracy
Dehumidification capacity
voltage
power
Maximum power
Air volume
refrigerant
Type of protection against electric shock
Body size
weight
Applicable temperature
Applicable area (height 3 meters)
AY-6.8DS
10% - 95%.
Plus or minus 3%
6.8 kg/h
220V-50Hz
1900W
2400W
1500m³/h
R22/R410A
Class I
615×405×1565mm
90kg
5 ℃ - 38 ℃
200-250m²
AY-10S
10% - 95%.
Plus or minus 3%
10kg/h
380V-50Hz
3150W
3900W
2000m³/h
R22/R410A
Class I
760×470×1710mm
126kg
5 ℃ - 38 ℃
300-400m²
AY-12S
10% - 95%.
Plus or minus 3%
12kg/h
380V-50Hz
3400W
4150W
2500m³/h
R22/R410A
Class I
760×470×1710mm
132kg
5 ℃ - 38 ℃
400-450m²
AY-20S
10% - 95%.
Plus or minus 3%
20kg/h
380V-50Hz
5500W
6600W
3500m³/h
R22/R410A
Class I
980×470×1770mm
176kg
5 ℃ - 38 ℃
600-800m²
