Two-way flow fresh air purification dehumidifier

Applicable environment：Widely used in home environment, hotel rooms, commercial offices, school classrooms, hospital recuperation, precision experiments, entertainment and fitness, underground warehouses, wine warehouses, bank vaults, civil air defense engineering and many other fields

Product Features：

Special custom：no

Quality Certification：

Model：AY-S28XAY-S40XAY-S60XAY-S100XAY-S140X

Buy Online Download

Product parameter

  1. Device model

  2. Test conditions

  3. Dehumidification capacity

  4. Supply air residual pressure

  5. Fan type

  6. Supply air volume

  7. Fresh air volume

  8. Return air volume

  9. Exhaust volume

  10. Power/current

  11. Voltage frequency

  12. way to control

  13. Electricity/Waterproof

  14. noise

  15. compressor

  16. Heat Exchanger

  17. Shui Pan

  18. Drainage pipe diameter

  19. Filter (optional)

  20. Purification (optional))

  21. New air outlet

  22. Air return

  23. Outlet

  24. Exhaust port

  25. Dimensions

  26. Net weight kg

  27. A-mm/B-mm

  1. AY-S28X

  2. 30℃ 80%

  3. 28L/day

  4. 100 Pa

  5. Two gears

  6. 320-420m³/h

  7. 100-150m³/h

  8. 220-420m³/h

  9. 80m³/h

  10. 550W/2.5A

  11. 220V/50Hz

  12. Full touch LCD liquid crystal

  13. Class I/IPX3

  14. <45DB


  15. Embraco/R134A

  16. Hydrophilic aluminum foil copper tube

  17. 304 stainless steel pipe

  18. DN20

  19. Initial effect/medium effect/high efficiency

  20. UV sterilization/anion

  21. Φ150mm

  22. Φ150mm

  23. Φ150mm

  24. Φ150mm

  25. 1205*699*283mm

  26. 60kg

  27. 1050mm/460mm

  1. AY-S40X

  2. 30℃ 80%

  3. 40L/day

  4. 150 Pa

  5. Two gears

  6. 650-780m³/h

  7. 180-250m³/h

  8. 400-780m³/h

  9. 120m³/h

  10. 720W/3.2A

  11. 220V/50Hz

  12. Full touch LCD liquid crystal

  13. Class I/IPX3

  14. <45DB


  15. Embraco/R134A

  16. Hydrophilic aluminum foil copper tube

  17. 304 stainless steel pipe

  18. DN20

  19. Initial effect/medium effect/high efficiency

  20. UV sterilization/anion

  21. Φ150mm

  22. Φ150mm

  23. Φ150mm

  24. Φ150mm

  25. 1205*699*283mm

  26. 60kg

  27. 1050mm/460mm

  1. AY-S60X

  2. 30℃ 80%

  3. 60L/day

  4. 150 Pa

  5. Two gears

  6. 730-850m³/h

  7. 280-360m³/h

  8. 450-850m³/h

  9. 200m³/h

  10. 850W/3.7A

  11. 220V/50Hz

  12. Full touch LCD liquid crystal

  13. Class I/IPX3

  14. <45DB


  15. Embraco/R134A

  16. Hydrophilic aluminum foil copper tube

  17. 304 stainless steel pipe

  18. DN20

  19. Initial effect/medium effect/high efficiency

  20. UV sterilization/anion

  21. Φ150mm

  22. Φ150mm

  23. Φ150mm

  24. Φ150mm

  25. 1205*699*283mm

  26. 68kg

  27. 1050mm/460mm

  1. AY-S100X

  2. 30℃ 80%

  3. 100L/day

  4. 150 Pa

  5. Inverter fan

  6. 1000-1200m³/h

  7. 430-550m³/h

  8. 570-1200m³/h

  9. 300m³/h

  10. 1100W/5A

  11. 220V/50Hz

  12. Full touch LCD liquid crystal

  13. Class I/IPX3

  14. <45DB


  15. Embraco/R134A

  16. Hydrophilic aluminum foil copper tube

  17. 304 stainless steel pipe

  18. DN20

  19. Initial effect/medium effect/high efficiency

  20. UV sterilization/anion

  21. Φ200mm

  22. Φ200mm

  23. Φ200mm

  24. Φ200mm

  25. 1330*749*325mm

  26. 85kg

  27. 1150mm/470mm

  1. AY-S140X

  2. 30℃ 80%

  3. 140L/day

  4. 150 Pa

  5. Inverter fan

  6. 1200-1380m³/h

  7. 580-720m³/h

  8. 770-1380m³/h

  9. 420m³/h

  10. 1380W/6.2A

  11. 220V/50Hz

  12. Full touch LCD liquid crystal

  13. Class I/IPX3

  14. <45DB


  15. Embraco/R134A

  16. Hydrophilic aluminum foil copper tube

  17. 304 stainless steel pipe

  18. DN20

  19. Initial effect/medium effect/high efficiency

  20. UV sterilization/anion

  21. Φ200mm

  22. Φ200mm

  23. Φ200mm

  24. Φ200mm

  25. 1330*749*325mm

  26. 92kg

  27. 1150mm/470mm
